The Double Pole RCCB / RCD Breakers Type A from ESR are available in a range of amp ratings including 16 Amp, 25 Amp, 40 Amp, 63 Amp and 80 Amp. This range includes the RCD2/A-1630, RCD2/A-2530, RCD2/A-4030, RCD2/A-6330, RCD2/A-63100, RCD2/A-8030 and RCD2/A-80100 models.

An RCD is a sensitive current breaker designed to protect the user and their property from electric shock and potential fires by breaking the current as is passes through your consumer unit in the event of a detected imbalance or disruption to current path. RCDs are known to save lives and are a commonly used component in domestic consumer unit configurations.

These RCD modules will use 2 modules/ways on your ESR consumer unit rail bar, and will trip the entire circuit associated with it in the event of a detected fault.

These modules are ideal for use with lighting/heating circuits in B curve (uses where switching surges are low or non-existent).

These RCCB modules are designed to trip at a 30mA imbalance with 100mA options available. We advise consulting your electrician if you are unsure which current rating is right for your desired application, as the wrong type may cause unnecessary tripping or create a potential hazard.

Main Features:
Double pole RCCB circuit breakers in a range of current options
Easily installed in your ESR modular consumer unit
Safe and reliable product that is known to save lives and severely reduce risk of property damage

Technical Specification:
Voltage: 230V
Frequency: 50 Hz
Modular size: 2 Module/way
Pole: Double Pole
Trip current rating: 30mA/100mA
Voltage: 230V
BS EN61008-1

Models in this range:
RCD2/A-1630 – Type A 2 Pole RCD, 16a 30ma
RCD2/A-2530 – Type A 2 Pole RCD, 25a 30ma
RCD2/A-4030 – Type A 2 Pole RCD, 40a 30ma
RCD2/A-6330 – Type A 2 Pole RCD, 63a 30ma
RCD2/A-63100 – Type A 2 Pole RCD, 63a 100ma
RCD2/A-8030 – Type A 2 Pole RCD, 80a 30ma
RCD2/A-80100 – Type A 2 Pole RCD, 80a 100ma
