Product Features

• 6-year limited tank & parts warranty, 1-year labor warranty
• Electronic gas control valve that provides precise temperature control and operational status
• Piezo igniter allows for easy one-hand pilot ignition without matches
• PEX dip tube
• Glass-lined tank with anode rod protects against corrosion
• Environmentally-Friendly Non-CFC foam insulation
• Factory-installed PEX polymer lined heat trap nipples
• Factory-installed temperature & pressure (T&P) relief valve

Specs

Tech Specs

• Nominal Capacity: 40
• Rated Storage Volume: 38
• UEF:0.58
• Family Size:4
• Self Cleaning:Yes
• Limited Warranty Tank:6
• Limited Warranty Parts:6
• Limited Warranty Labor:1
• Max BTUs Input:40,000
• Emissions:Low NOx
• Foam Insulation:Yes
• Water Connection Location:Top
• Water Connection Size:3/4
• UPC:91193004838
• First Hour Rating (Gallons):67

Dimensions

• Height:47 3/4″
• Height w/Draft Hood (inches):51 1/2″
• Diameter:22″
• Width:22″
• Depth:22″
• Vent Size:
